| CM-330 Series Hands Free Switches |
|
|
NEW SUREWAVE(TM) WIRELESS SWITCH KITS ARE NOW AVAILABLE FOR ORDER!
CM-330 Series are 2nd generation hands-free switches from Camden. We started by designing a switch to provide superior door activation in new and retrofit access control and automatic door applications, and then built in our industry-leading experience in serving thousands of installations. The result is an unprecedented level of easy installation (in any application), rock solid performance (wired & wireless) and years of trouble free service. CM-330 and CM-333 battery powered models supplied with (2) AA alkaline batteries. Lithium batteries recommended for environments below 0°C (32°F). To order, select option below. CM-324 Series (original) single relay wired hands-free switches features an operating range of 1-30", adjustable time delay of 1-5 seconds, and provides superior performance in all ambient lighting conditions.
CM-325 Series hands-free switches are specifically designed for use in healthcare and facilities where highly reflective surfaces (chrome or polished stainless steel) cause standard touchless switches to false activate.
Add 'F' to graphic option for French language.
|
|
|
| CM-331/42R-SGLR Round 6" Stainless Steel Faceplate with Light Ring |
|
|
|
| CM-331/42WS-SGLR, Double Gang, SS Faceplate with LED light Ring |
|
|
|
| Part of Our Touchless Wave Product Family |
|
COMPETITIVE MODELS
|
|
|
|
This product series is generally equivalent to the following competitive model(s):
|
| Manufacturer |
Part Number |
|
Alarm Controls
|
NTS-1, NTS-2, NTS-3
|
|
BEA
|
10MS11D, 10MS11J, 10MS11S, 70.5226, 70.5227, 70.5272, 70.5273
|
|
Dormakaba (RCI)
|
910TC, 912
|
|
MS Sedco
|
216, 216-L, 216-N, 216TX-HT, 216TX-HT, NGS-IR-A
|
|
Securitron
|
WSSW1, WSSW2
|
|
Wikk
|
4X4NOTOUCH32D, SFANOTOUCH32D
|
|
|
| CM-330 Series Hands Free Switches |
|
|
NEW SUREWAVE(TM) WIRELESS SWITCH KITS ARE NOW AVAILABLE FOR ORDER!
CM-330 Series are 2nd generation hands-free switches from Camden. We started by designing a switch to provide superior door activation in new and retrofit access control and automatic door applications, and then built in our industry-leading experience in serving thousands of installations. The result is an unprecedented level of easy installation (in any application), rock solid performance (wired & wireless) and years of trouble free service. CM-330 and CM-333 battery powered models supplied with (2) AA alkaline batteries. Lithium batteries recommended for environments below 0°C (32°F). To order, select option below. CM-324 Series (original) single relay wired hands-free switches features an operating range of 1-30", adjustable time delay of 1-5 seconds, and provides superior performance in all ambient lighting conditions.
CM-325 Series hands-free switches are specifically designed for use in healthcare and facilities where highly reflective surfaces (chrome or polished stainless steel) cause standard touchless switches to false activate.
Add 'F' to graphic option for French language.
|
|
|
|
COMPETITIVE MODELS
|
|
|
|
This product series is generally equivalent to the following competitive model(s):
|
| Manufacturer |
Part Number |
|
Alarm Controls
|
NTS-1, NTS-2, NTS-3
|
|
BEA
|
10MS11D, 10MS11J, 10MS11S, 70.5226, 70.5227, 70.5272, 70.5273
|
|
Dormakaba (RCI)
|
910TC, 912
|
|
MS Sedco
|
216, 216-L, 216-N, 216TX-HT, 216TX-HT, NGS-IR-A
|
|
Securitron
|
WSSW1, WSSW2
|
|
Wikk
|
4X4NOTOUCH32D, SFANOTOUCH32D
|
| |
|
| FEATURES |
|
SPECIFICATIONS |
|
RESOURCES |
|
VIDEOS |
|
|
- Wired, wireless and hybrid (wirless/wired) models
- Indoor/outdoor use. -4ºF to +153ºF (-20ºC to +85ºC) operating temp. Gasket included in package
- Battery powered wireless models offer 2 year battery life using standard 'AA' alkaline batteries
- Line powered models offer 12/24V AC/DC operation
- 1 and 2 relay wired models, SPDT, Form 'C'
- Narrow (jamb), single and and double gang faceplates
- Polycarbonate (black) and stainless steel faceplates
- Advanced active infra-red technology with fast response
- Heavy duty 3 or 5 Amp rated relay
- Adjustable operating range up to 28", refer to model specification
- CM-331/332 Series: Selectable auto range (operation) mode of up to 6"
- Adjustable time delay, refer to model specifcation
- Selectable fail safe/fail secure operation
- CM-331/332 Series: Active output for external alrm, LED or annunciator
- CM-332/333 Series: 'Request to exit' and external door contact inputs
- CM-331/332 Series: Optional red/blue/green LED light ring with single gang stainless steel faceplate, indicates switch or door status
| Technology: |
Active Infra-red, utilizing microburst sensing technology |
| Voltage: |
12-24V AC/DC |
| Contact Type: |
CM-331/333/324/325: (1) SPDT Form 'C'
CM-332: (2) SPDT Form 'C' |
| Contact Rating: |
CM-331/332/333: 3 Amps @ 30 V
CM-324/325: 5 Amps @ 30 V |
| Current Draw: |
CM-331/332: 40 mA
CM-324/325: 60 mA |
| Wireless: |
CM-330: Built-In
CM-331/332/333: Optional Plug-In |
| Wireless Frequency: |
CM-330 Series: 915 Mhz. Lazerpoint RF™ Spread Spectrum Wireless |
| Battery: |
CM-330/333:
(2) 'AA' alkaline
-0ºF to +153º F (-18ºC to +85º C)
(2) AA Lithium Batteries (optional)
-4ºF to +153º F (-20ºC to +85º C) |
| Battery Life: |
Alkaline: 2 years with 100 activations per day |
| Adjustable Operating Range: |
CM-331/332: 1"- 28" (25mm-711mm)
CM-330/333: 1"-12" (25mm-304mm)
CM-324: 1"-30" (25.4mm-762mm)
CM-325: Min. 2" (51mm) Hand, Max. 18" (45mm) Mirror |
| Time Delay: |
CM-330/331/332/333: 3-30 Seconds
CM-324/325: 1-5 Seconds |
| Operation: |
Selectable Fail Safe/Fail Secure |
| Montion Sensing Modes: |
CM-331/332/333: Momentary, Momentary with Alarm, Maintained
CM-330/324/325: Momentary |
| Relay Operating Modes: |
CM-332: Event, Sequence, Security, Toggle
CM-331: Event, Toggle
CM-330/333/324/325: Event |
| Input: |
CM-331/332/333: REX, Door Contact |
| Blue/Green/Red Light Ring: |
CM-331/332: Optional |
|
Spec Sheets
|
| CM-324 & 325_Spec Sheet |
pdf |
2.00 |
DOWNLOAD
|
| CM-330_Spec Sheet_R4 |
pdf |
2.00 |
DOWNLOAD
|
| CM-331_Spec Sheet |
pdf |
1.64 |
DOWNLOAD
|
| CM-332_Spec Sheet |
pdf |
1.51 |
DOWNLOAD
|
| CM-333_Spec Sheet_R2 |
pdf |
1.91 |
DOWNLOAD
|
|
Reference Guides
|
| SureWave™ Model Selection Guide |
pdf |
0.64 |
DOWNLOAD
|
| SureWave(tm) Touchless Switch Presentation- Options & Applications |
pdf |
1.51 |
DOWNLOAD
|
| SureWave™ Product Comparison |
pdf |
0.19 |
DOWNLOAD
|
| SureWave™ Application Guide |
pdf |
5.90 |
DOWNLOAD
|
|
Manuals
|
| CM-324_Manual_R4 |
pdf |
0.45 |
DOWNLOAD
|
| CM-325_Manual_R2 |
pdf |
0.41 |
DOWNLOAD
|
| CM-325_Manual_French_R2 |
pdf |
0.44 |
DOWNLOAD
|
| CM-330_Manual_R2 |
pdf |
0.93 |
DOWNLOAD
|
| CM-330_Manual_French_R2 |
pdf |
0.90 |
DOWNLOAD
|
| CM-331_CM-332_Manual_R2 |
pdf |
0.89 |
DOWNLOAD
|
| CM-331_CM-332_Manual_French_R2 |
pdf |
0.90 |
DOWNLOAD
|
| CM-333_Manual_R2 |
pdf |
0.67 |
DOWNLOAD
|
| CM-333_Manual_French_R2 |
pdf |
0.68 |
DOWNLOAD
|
|
High Resolution Images
|
| CM-331/41N |
jpeg |
1.54 |
DOWNLOAD
|
| CM-325/42SW |
jpeg |
0.92 |
DOWNLOAD
|
| CM-331/41W |
jpeg |
2.73 |
DOWNLOAD
|
| CM-331/42SW-SGLR |
jpeg |
1.01 |
DOWNLOAD
|
| CM-331/43S-SGLR |
jpeg |
0.85 |
DOWNLOAD
|
Touchless WaveProduct Line Overview
SureWave IntroductionDiscover our range of Touchless Switches
CM-330Battery Powered Touchless Switches
CM-3311 Relay Touchless Switches
CM-3322 Relay Touchless Switches
CM-333Hybrid Battery Powered Switch - 1 Relay
6" Round FaceplateNew SureWave Switch Option
|
|
MODELS
|
|
Click to configure switch model
|
|
|
|
WIZARD
|
| SELECT MODEL |
 |
|
|
|
|
WIZARD
|
| SELECT MODEL |
|
|
|
|
Touchless Switch, 1 Relay
click to expand section
|
|
Net Cost
|
|
|
CM-331
Wired Touchless switch, w/ built-in door control, 1 Relay, option for CM-TX99 wireless transmitter and light ring
EDI DATA, APPROVALS
|
|
Wired Touchless switch, w/ built-in door control, 1 Relay, option for CM-TX99 wireless transmitter and light ring
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: 5.25"L x 5.5"W x 2"H
Weight: 0.4lbs.
UPC:670454180988
|
|
|
CM-324
Wired Touchless Switch, economical, 1 Relay, no inputs, wireless or light ring
EDI DATA, APPROVALS
|
|
Wired Touchless Switch, economical, 1 Relay, no inputs, wireless or light ring
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: 4"L x 1"W x 1.5"H
Weight: 0.4lbs.
UPC:670454160935
|
|
|
CM-325
Wired 'Short Range' Touchless Switch, 1 Relay, no inputs, wireless or light ring
EDI DATA, APPROVALS
|
|
Wired 'Short Range' Touchless Switch, 1 Relay, no inputs, wireless or light ring
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: 5.25"L x 5.5"W x 2"H
Weight: 0.4lbs.
UPC:670454178565
|
| |
|
Touchless Switch, 2 Relays
click to expand section
|
|
Net Cost
|
|
|
CM-332
Wired Touchless Switch, w/ built-in door control, 2 Relays, option for CM-TX99 wireless transmitter and light ring
EDI DATA, APPROVALS
|
|
Wired Touchless Switch, w/ built-in door control, 2 Relays, option for CM-TX99 wireless transmitter and light ring
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: 5.25"L x 5.5"W x 2"H
Weight: 0.4lbs.
UPC:670454180995
|
| |
|
Touchless Switch, Battery Powered
click to expand section
|
|
Net Cost
|
|
|
CM-333
Hybrid Battery Powered Touchless Switch, 1 wired Relay, option for CM-TX99 wireless transmitter.
EDI DATA, APPROVALS
|
|
Hybrid Battery Powered Touchless Switch, 1 wired Relay, option for CM-TX99 wireless transmitter.
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: 5.25"L x 5.5"W x 2"H
Weight: 0.4lbs.
UPC:670454181008
|
|
|
CM-330
Battery Powered, Wireless Touchless Switch, w/ built-in Lazerpoint RF(tm) wireless transmitter.
EDI DATA, APPROVALS
|
|
Battery Powered, Wireless Touchless Switch, w/ built-in Lazerpoint RF(tm) wireless transmitter.
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: 5.25"L x 5.5"W x 2"H
Weight: 0.4lbs.
UPC:670454180971
|
| |
|
|
OPTIONS & FINISHES
|
|
|
Click to expand section
|
|
|
|
|
WIZARD
|
| SELECT OPTIONS |
|
|
|
|
|
WIZARD
|
|
SELECT FACEPLACE GRAPHIC
|
|
|
|
|
|
WIZARD
|
| SELECT MODEL ABOVE |
 |
|
|
|
|
WIZARD
|
| SELECT OPTIONS |
|
|
|
|
 |
| FACEPLATE OPTIONS |
 |
| FACEPLATE GRAPHIC OPTIONS |
 |
| LED OPTIONS |
 |
| LITHIUM BATTERY OPTION |
|
| Faceplate Material |
|
Net Cost |
|
|
CM-xxxS
Stainless Steel Faceplate
|
Stainless Steel Faceplate
|
|
|
| Faceplate Size |
|
Net Cost |
|
|
/N
Narrow Faceplate. Rubber gasket supplied for weather/water resistant applications. Compatible with narrow jamb surface mount box CM-23D, except for models using CM-TX99 plug-in wireless transmitter.
|
Narrow Faceplate. Rubber gasket supplied for weather/water resistant applications. Compatible with narrow jamb surface mount box CM-23D, except for models using CM-TX99 plug-in wireless transmitter.
|
|
|
|
|
/W
Double Gang Faceplate. Rubber gasket supplied for weather/water resistant applications. Compatible surface mounting box CM-43CBLA
|
Double Gang Faceplate. Rubber gasket supplied for weather/water resistant applications. Compatible surface mounting box CM-43CBLA
|
|
|
|
|
/R
6" Round Faceplate, Stainless Steel Only, NOT WATER/WEATHER RESISTANT. 'SGLR' light ring option required for illumination. Mounts on single gang in-wall electrical box, alone or with semi-flush CM-79A escutcheon.
|
6" Round Faceplate, Stainless Steel Only, NOT WATER/WEATHER RESISTANT. 'SGLR' light ring option required for illumination. Mounts on single gang in-wall electrical box, alone or with semi-flush CM-79A escutcheon.
|
|
|
| Faceplate Graphic Options |
|
Net Cost |
|
/40
Hand Icon
|
Hand Icon
|
|
|
|
/41
Hand Icon and 'Wave to Open' text
|
Hand Icon and 'Wave to Open' text
|
|
|
|
/42
Hand Icon, 'Wave to Open' text and Wheelchair Symbol
|
Hand Icon, 'Wave to Open' text and Wheelchair Symbol
|
|
|
|
/43
Hand Icon and 'Wave To Lock'. Option for stainless steel face plate only. Door locked status indicator recommended when using this graphic option.
|
Hand Icon and 'Wave To Lock'. Option for stainless steel face plate only. Door locked status indicator recommended when using this graphic option.
|
|
|
|
/44
Hand Icon and Wheelchair Symbol
|
Hand Icon and Wheelchair Symbol
|
|
|
| Light Ring |
|
Net Cost |
|
-SGLR
Plug-in light ring for single gang, double gang and 6" round stainless steel faceplates. Red/Green/Blue controlled by switch or remotely. Switch is not weather/water resistant with the selection of this option.
|
Plug-in light ring for single gang, double gang and 6" round stainless steel faceplates. Red/Green/Blue controlled by switch or remotely. Switch is not weather/water resistant with the selection of this option.
|
|
|
| Lithium Batteries |
|
Net Cost |
|
|
-L1
Add suffix '-L1" for (2) 'AA' Lithium Batteries in place of (2) Alkaline. CM-330 and CM-333 models only.
|
Add suffix '-L1" for (2) 'AA' Lithium Batteries in place of (2) Alkaline. CM-330 and CM-333 models only.
|
|
|
|
|
CM-LP1
(2) AA lithium battery pack
|
(2) AA lithium battery pack
|
|
|
|
|
|
|
Packaging Weights & Dimensions:
|
|
|
COMPATIBLE WIRELESS
|
|
|
Click to expand section
|
|
|
|
| |
|
Net Cost |
|
CM-TX99
915Mhz. plug-in transmitter for SureWave(tm) CM-331, 332 and 333 series touchless switches and CM-120 Series Keypads
|
915Mhz. plug-in transmitter for SureWave(tm) CM-331, 332 and 333 series touchless switches and CM-120 Series Keypads
|
|
|
|
CM-RX-90
V2 Lazerpoint RF(tm) & Kinetic(tm) Compatible Single Relay Receiver
|
V2 Lazerpoint RF(tm) & Kinetic(tm) Compatible Single Relay Receiver
|
|
|
|
COMPATIBLE MOUNTING BOXES
|
|
|
Click to expand section
|
|
|
|
| |
|
Net Cost |
|
CM-23D
Surface Box, Extra Deep - For wireless. Flame and Impact resistant black polymer (ABS) 1-3/4"W x 4-1/2"H X 1-1/2"D. Not compatible with CM-333 narrow SureWave(tm) battery powered touchless switch.
|
Surface Box, Extra Deep - For wireless. Flame and Impact resistant black polymer (ABS) 1-3/4"W x 4-1/2"H X 1-1/2"D. Not compatible with CM-333 narrow SureWave(tm) battery powered touchless switch.
|
|
|
|
CM-34BL
Surface Box, Standard Depth. Double wall flame/impact resistant black ABS, 2-3/4"W x 4-1/2"H x 1-3/4"D
|
Surface Box, Standard Depth. Double wall flame/impact resistant black ABS, 2-3/4"W x 4-1/2"H x 1-3/4"D
|
|
|
|
CM-43CBLA
Surface mounting box Flame/Impact resistant, 4-1/2"W x 4-1/2"H x 2"D. For used with CM-324/325/330 Series double gang Hands Free Switches
|
Surface mounting box Flame/Impact resistant, 4-1/2"W x 4-1/2"H x 2"D. For used with CM-324/325/330 Series double gang Hands Free Switches
|
|
|
|
CM-79A
Flush enclosure only (fits single gang box) 8' x 3/4"
|
Flush enclosure only (fits single gang box) 8' x 3/4"
|
|
|
|
|
|
|
CM-330 Series Battery Powered Wireless Kits
click to expand section
|
|
Net Cost
|
|
|
CM-SK330/42SN
EDI DATA, APPROVALS
|
|
CM-SK330/42SN
(2)
SureWave(tm) wireless no-touch switch, narrow, stainless steel faceplate, 'Wave to Open' graphics, black;
(2)
Surface Box, Extra Deep;
(1)
V2 Lazerpoint RF(tm) & Kinetic(tm) Compatible Single Relay Receiver.
EDI DATA, APPROVALS
| 2x |
|
| 2x |
|
| 1x |
|
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: "L x "W x "H
Weight: lbs.
|
|
|
CM-SK330/42S
EDI DATA, APPROVALS
|
|
CM-SK330/42S
(2)
SureWave(tm) wireless no-touch switch, single gang, stainless steel faceplate, 'Wave to Open' graphics, black;
(2)
Surface Box, Standard Depth. Double wall;
(1)
V2 Lazerpoint RF(tm) & Kinetic(tm) Compatible Single Relay Receiver.
EDI DATA, APPROVALS
| 2x |
|
| 2x |
|
| 1x |
|
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: "L x "W x "H
Weight: lbs.
|
|
|
CM-SK330/42SW
EDI DATA, APPROVALS
|
|
CM-SK330/42SW
(2)
SureWave(tm) wireless no-touch switch, double gang, stainless steel faceplate, 'Wave to Open' graphics, black;
(2)
Surface mounting box;
(1)
V2 Lazerpoint RF(tm) & Kinetic(tm) Compatible Single Relay Receiver.
EDI DATA, APPROVALS
| 2x |
|
| 2x |
|
| 1x |
|
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: "L x "W x "H
Weight: lbs.
|
|
|
CM-SK330/42SR
EDI DATA, APPROVALS
|
|
CM-SK330/42SR
(2)
SureWave(tm) wireless no-touch switch, 6" Round, stainless steel faceplate, 'Wave to Open' graphics, black;
(2)
Semi-flush escutcheon, fits single gang in-wall box;
(1)
V2 Lazerpoint RF(tm) & Kinetic(tm) Compatible Single Relay Receiver.
EDI DATA, APPROVALS
| 2x |
|
| 2x |
|
| 1x |
|
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: "L x "W x "H
Weight: lbs.
|
| |
|
CM-331 Series 12/24V Powered Wireless Kits
click to expand section
|
|
Net Cost
|
|
|
CM-SK331/42SN
EDI DATA, APPROVALS
|
|
CM-SK331/42SN
(2)
SureWave(tm) line powered, 1 relay no-touch switch, narrow, stainless steel faceplate, 'Wave to Open' graphics, black;
(2)
Lazerpoint RF(tm) 915Mhz. plug-in transmitter for SureWave(tm) no-touch switch;
(2)
Narrow Surface Box, Extra Deep;
(1)
V2 Lazerpoint RF(tm) & Kinetic(tm) Compatible Single Relay Receiver.
EDI DATA, APPROVALS
| 2x |
|
| 2x |
|
| 2x |
|
| 1x |
|
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: "L x "W x "H
Weight: lbs.
|
|
|
CM-SK331/42S-LR
EDI DATA, APPROVALS
|
|
CM-SK331/42S-LR
(2)
SureWave(tm) line powered, 1 relay no-touch switch, single gang, stainless steel faceplate, w/ light ring, 'Wave to Open' graphics, black;
(2)
Lazerpoint RF(tm) plug-in wireless transmitter;
(2)
Single gang surface box, standard depth;
(1)
V2 Lazerpoint RF(tm) & Kinetic(tm) Compatible Single Relay Receiver.
EDI DATA, APPROVALS
| 2x |
|
| 2x |
|
| 2x |
|
| 1x |
|
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: "L x "W x "H
Weight: lbs.
|
|
|
CM-SK331/42SW-LR
EDI DATA, APPROVALS
|
|
CM-SK331/42SW-LR
(2)
SureWave(tm) line powered, 1 relay no-touch switch, double gang, stainless steel faceplate, w/ light ring, 'Wave to Open' graphics, black;
(2)
Lazerpoint RF(tm) plug-in wireless transmitter;
(2)
Double gang surface box for SureWave(tm) switch;
(1)
V2 Lazerpoint RF(tm) & Kinetic(tm) Compatible Single Relay Receiver.
EDI DATA, APPROVALS
| 2x |
|
| 2x |
|
| 2x |
|
| 1x |
|
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: "L x "W x "H
Weight: lbs.
|
|
|
CM-SK331/42R-LR
EDI DATA, APPROVALS
|
|
CM-SK331/42R-LR
(2)
SureWave(tm) line powered, 1 relay no-touch switch, 6" round, stainless steel faceplate, w/ light ring, 'Wave to Open' graphics, black;
(2)
Lazerpoint RF(tm) plug-in wireless transmitter;
(2)
Semi-flush Escutcheon, fits single gang box;
(1)
V2 Lazerpoint RF(tm) & Kinetic(tm) Compatible Single Relay Receiver.
EDI DATA, APPROVALS
| 2x |
|
| 2x |
|
| 2x |
|
| 1x |
|
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: "L x "W x "H
Weight: lbs.
|
| |
|
|
Lazerpoint RF
This product series is designed for use with the industry's most reliable and easy to install wireless system!
|
|
|
