| CM-7536VR/4 Column™ Push Plate with Hands Free Sensor |
|
All switches shown with graphics as examples. Select your graphic in the 'Options & Finishes' section below.
|
|
|
|
CM-74 & CM-75 Series Column™ switches offer greater user convenience and lower installation costs by providing a single activation device in place of two high/low switches, as required by a growing number of building codes across North America. These Column™ switches feature solid aluminum or stainless steel construction and are available in a range of finishes. Also available is the option for Kinetic by CamdenTM no-battery wireless or Lazerpoint™ battery powered wireless transmitters. The VR Series Column™ switches with hands-free sensors use active infra-red technology to eliminate the spread of germs. - Kinetic™ no-battery wireless now available on CM-7536 series Column™ switches. Not available on 9" tall models.
- DPDT switch option not available. Use Camden CX-IRB relay if required.
|
|
|
| 36" Long Column™ Push Plate Switch with Blue Anodized Finish |
|
|
|
| 36" Long Column™ Push Plate Switch with Dark Bronze Anodized Finish |
|
|
|
| Stainless Steel Column Switches Available |
|
|
|
| Part of Our Touchless Wave Product Family |
|
|
|
| Available inKinetic™ Models |
|
COMPETITIVE MODELS
|
|
|
|
This product series is generally equivalent to the following competitive model(s):
|
| Manufacturer |
Part Number |
Camden Part Number |
|
BEA
|
10LPR36-HW
|
CM-7536, CM-xxx/4
|
|
|
10LPR36L-900
|
CM-7536/4-TX
|
|
|
10PR36L-HW
|
CM-7536, CM-xxx/2
|
|
Dormakaba (RCI)
|
9LP36-433X32D
|
CM-7536/4TX
|
|
|
9LP36-HWX32D
|
CM-7536, CM-xxx/4
|
|
Wikk
|
136-3BLUE
|
CM-7536, CM-xxx/4, CM-BLU
|
|
|
136-5
|
CM-7536, CM-xxx/2
|
|
|
I36-3
|
CM-7536, CM-xxx/4
CM-7536, CM-xxx/4
|
|
|
I36-5DARKBRONZE
|
CM-7536, CM-xxx/4, CM-BRZ
|
|
|
| CM-7536VR/4 Column™ Push Plate with Hands Free Sensor |
|
CM-74 & CM-75 Series Column™ switches offer greater user convenience and lower installation costs by providing a single activation device in place of two high/low switches, as required by a growing number of building codes across North America. These Column™ switches feature solid aluminum or stainless steel construction and are available in a range of finishes. Also available is the option for Kinetic by CamdenTM no-battery wireless or Lazerpoint™ battery powered wireless transmitters. The VR Series Column™ switches with hands-free sensors use active infra-red technology to eliminate the spread of germs. - Kinetic™ no-battery wireless now available on CM-7536 series Column™ switches. Not available on 9" tall models.
- DPDT switch option not available. Use Camden CX-IRB relay if required. |
|
|
|
|
|
COMPETITIVE MODELS
|
|
|
|
This product series is generally equivalent to the following competitive model(s):
|
| Manufacturer |
Part Number |
Camden Part Number |
|
BEA
|
10LPR36-HW
|
CM-7536, CM-xxx/4
|
|
|
10LPR36L-900
|
CM-7536/4-TX
|
|
|
10PR36L-HW
|
CM-7536, CM-xxx/2
|
|
Dormakaba (RCI)
|
9LP36-433X32D
|
CM-7536/4TX
|
|
|
9LP36-HWX32D
|
CM-7536, CM-xxx/4
|
|
Wikk
|
136-3BLUE
|
CM-7536, CM-xxx/4, CM-BLU
|
|
|
136-5
|
CM-7536, CM-xxx/2
|
|
|
I36-3
|
CM-7536, CM-xxx/4
CM-7536, CM-xxx/4
|
|
|
I36-5DARKBRONZE
|
CM-7536, CM-xxx/4, CM-BRZ
|
| |
|
| FEATURES |
|
SPECIFICATIONS |
|
RESOURCES |
|
VIDEOS |
|
|
- Low profile contoured design with easy activation from side angles
- Meets or exceeds California building code, section 1117B.6 requirements
- Over 94 square inches total activation area (CM-7536)
- (2) Fully redundant SPDT, 15 Amp. UL listed switches (CM-7536)
- Choice of aluminum switch with clear, dark bronze or blue architectural finishes and stainless steel
- Choice of 4 different stock graphics
- Optional 'snap-in' Lazerpoint RF™ wireless transmitters
- Adjustable leveling screws for easy installation on uneven walls
- No internal wires exposed to moving parts
- IR Sensor provides stable and reliable operation
- Red/green light ring with switch or remote activation
- Adjustable sensor range 2" to 8" (5cm to 20cm)
- Adjustable sensor time delay (0.5 sec. to 20 sec.)
- Weather/water resistant sensor, IP65 rated
| Voltage: |
CM-7509/7536: N/A CM-7536VR: 12-24 VDC +/- 10% |
| Contact Type: |
CM-7509/7536: SPDT Momentary, Form 'C' CM-7536VR: Common / N.O. / N.C. |
| Contact Rating: |
CM-7509/7536: 15 Amps @ 30 VDC CM-7536VR: 1 Amp @ 30VDC |
| Dimensions: |
CM-7509: 5-7/8"W x 10-5/8"H x 1-1/2"D(150mm x 270mm x 38mm) CM-7536: 5-7/8"W x 37-1/2"H x 1-1/2"D (150mm x 953mm x 38mm) CM-7536VR: 5-7/8"W x 37-1/2"H x 1-1/2"D (150mm x 953mm x 38mm)
|
|
Manuals
|
| CM-75SB Series Surface Box (Op2) |
pdf |
1.07 |
DOWNLOAD
|
| CM-7436_Column Switch |
pdf |
0.48 |
DOWNLOAD
|
| CM-7436_Column Switch_FR |
pdf |
0.51 |
DOWNLOAD
|
| CM-7436VR_Column_Switch_W/Sensor_Manual |
pdf |
0.51 |
DOWNLOAD
|
| CM-7436VR_Column_Switch_W/Sensor_Manual_FR |
pdf |
0.56 |
DOWNLOAD
|
| CM-75 Manual_R2 |
pdf |
0.53 |
DOWNLOAD
|
| CM-75 Manual_R2_FR |
pdf |
0.48 |
DOWNLOAD
|
| CM-7536VR_Column_Switch_W/Sensor_Manual |
pdf |
0.53 |
DOWNLOAD
|
| CM-7536VR_Column_Switch_W/Sensor_Manual_FR |
pdf |
0.58 |
DOWNLOAD
|
|
High Resolution Images
|
| CM-7436 |
jpeg |
0.36 |
DOWNLOAD
|
| CM-7436VR |
jpeg |
0.36 |
DOWNLOAD
|
| CM-7536/4-BRZ |
jpeg |
0.89 |
DOWNLOAD
|
| CM-7509/4 |
jpeg |
1.35 |
DOWNLOAD
|
| CM-7536/4 |
jpeg |
0.84 |
DOWNLOAD
|
| CM-7536VR/4 |
png |
0.45 |
DOWNLOAD
|
| CM-7536SSVR/4 |
png |
0.56 |
DOWNLOAD
|
|
Spec Sheets
|
| CM-75 Series_Spec Sheet_R4 |
pdf |
4.85 |
DOWNLOAD
|
|
Reference Guides
|
| Column Switch PowerPoint Presentation |
pdf |
0.69 |
DOWNLOAD
|
| CM-75 Product Comparison |
pdf |
0.15 |
DOWNLOAD
|
| OBC Compliant Push Plate Switches_R2 |
pdf |
0.90 |
DOWNLOAD
|
| OBC Compliant Push Plate Switches_French_R2 |
pdf |
0.90 |
DOWNLOAD
|
Touchless WaveProduct Line Overview
|
|
MODELS
|
|
Click to configure switch model
|
|
|
|
WIZARD
|
| SELECT MODEL |
 |
|
|
|
|
WIZARD
|
| SELECT MODEL |
|
|
|
|
Wired Manual Switches
click to expand section
|
|
Net Cost
|
|
CM-7436
36" Column™ push plate switch, anodized aluminum finish. Option for dark bronze finish
EDI DATA, APPROVALS
|
|
36" Column™ push plate switch, anodized aluminum finish. Option for dark bronze finish
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: 40.5"L x 8.5"W x 4.5"H
Weight: lbs.
|
|
CM-7509
9" Long Column™ push plate switch, anodized aluminum finish, option for dark bronze or blue anodized finish. Option for dark bronze or blue anodized finish. Option for Lazerpoint™ battery powered wireless, receiver required.
EDI DATA, APPROVALS
|
|
9" Long Column™ push plate switch, anodized aluminum finish, option for dark bronze or blue anodized finish. Option for dark bronze or blue anodized finish. Option for Lazerpoint™ battery powered wireless, receiver required.
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: 12.5"L x 8.5"W x 4.5"H
Weight: 4.0lbs.
UPC:NA
|
|
CM-7536
36" Long Column™ push plate switch, anodized aluminum finish. Option for dark bronze or blue anodized finish. Option for Lazerpoint™ battery powered wireless, receiver required.
EDI DATA, APPROVALS
|
|
36" Long Column™ push plate switch, anodized aluminum finish. Option for dark bronze or blue anodized finish. Option for Lazerpoint™ battery powered wireless, receiver required.
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: 40.5"L x 8.5"W x 4.5"H
Weight: 7.0lbs.
UPC:NA
|
|
CM-7536SS
36" Long Column™ push plate switch, stainless steel. Option for Lazerpoint™ battery powered wireless, receiver required.
EDI DATA, APPROVALS
|
|
36" Long Column™ push plate switch, stainless steel. Option for Lazerpoint™ battery powered wireless, receiver required.
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: 40.5"L x 8.5"W x 4.5"H
Weight: 12.4lbs.
UPC:NA
|
| |
|
Wired Manual Switches with Hands-Free Sensor
click to expand section
|
|
Net Cost
|
|
CM-7436VR
36" Column™ Push Plate Switch With Hands-Free Sensor, Anodized Aluminum, Option for Bronze Finish
EDI DATA, APPROVALS
|
|
36" Column™ Push Plate Switch With Hands-Free Sensor, Anodized Aluminum, Option for Bronze Finish
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: 40.5"L x 8.5"W x 4.5"H
Weight: lbs.
UPC:670454219145
|
|
CM-7536VR
36" Long Column™ Push Plate Switch With Hands-Free Sensor, Anodized Aluminum Finish. Option for Dark Bronze or Blue Anodized Finish.
EDI DATA, APPROVALS
|
|
36" Long Column™ Push Plate Switch With Hands-Free Sensor, Anodized Aluminum Finish. Option for Dark Bronze or Blue Anodized Finish.
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: 40.5"L x 8.5"W x 4.5"H
Weight: 7.0lbs.
UPC:670454167422
|
|
CM-7536SSVR
36" Long Column™ Push Plate Switch With Hands-Free Sensor, Brushed Stainless Steel, US32 / 630
EDI DATA, APPROVALS
|
|
36" Long Column™ Push Plate Switch With Hands-Free Sensor, Brushed Stainless Steel, US32 / 630
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: 40.5"L x 8.5"W x 4.5"H
Weight: 7.0lbs.
|
| |
|
No Battery Wireless Switches with Transmitter
click to expand section
|
|
Net Cost
|
|
CM-7536K
36" Long Column™ push plate switch, aluminum, w/ built-in Kinetic™ no battery wireless transmitter, receiver required.
EDI DATA, APPROVALS
|
|
36" Long Column™ push plate switch, aluminum, w/ built-in Kinetic™ no battery wireless transmitter, receiver required.
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: 40.5"L x 8.5"W x 5.5"H
Weight: 7.0lbs.
UPC:NA
|
|
CM-7536SSK
36" Long Column™ push plate switch, stainless steel w/ built-in Kinetic™ no battery wireless transmitters, receiver required.
EDI DATA, APPROVALS
|
|
36" Long Column™ push plate switch, stainless steel w/ built-in Kinetic™ no battery wireless transmitters, receiver required.
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: 40.5"L x 8.5"W x 4.5"H
Weight: 12.4lbs.
UPC:NA
|
| |
|
|
OPTIONS & FINISHES
|
|
|
Click to expand section
|
|
|
|
|
WIZARD
|
| SELECT OPTIONS |
|
|
|
|
|
WIZARD
|
|
SELECT OPTIONS
|
|
|
|
|
|
WIZARD
|
| SELECT MODEL ABOVE |
 |
|
|
|
|
WIZARD
|
| SELECT OPTIONS |
|
|
|
|
 |
| FACEPLATE GRAPHIC OPTIONS |
 |
| ARCHITECTURAL FINISH OPTIONS |
 |
| LAZERPOINT RF(TM) BATTERY POWERED WIRELESS |
 |
| WEATHER RESISTANT OPTIONS |
|
| Faceplate Graphic Options |
|
Net Cost |
|
CM-xxx/2
'WHEELCHAIR' symbol, blue
|
'WHEELCHAIR' symbol, blue
|
|
|
|
CM-xxx/A2
'ACTIVE WHEELCHAIR' symbol, blue. Not available on stainless steel Column™ switches
|
'ACTIVE WHEELCHAIR' symbol, blue. Not available on stainless steel Column™ switches
|
|
|
|
CM-xxx/2AL
WHEELCHAIR symbol with ARROW left, blue graphics. CM-7536 aluminum finish only.
|
WHEELCHAIR symbol with ARROW left, blue graphics. CM-7536 aluminum finish only.
|
|
|
|
CM-xxx/2AR
WHEELCHAIR symbol with ARROW right, blue graphics. CM-7536 aluminum finish only.
|
WHEELCHAIR symbol with ARROW right, blue graphics. CM-7536 aluminum finish only.
|
|
|
|
CM-xxx/4
'WHEELCHAIR' symbol and 'PUSH TO OPEN', blue
|
'WHEELCHAIR' symbol and 'PUSH TO OPEN', blue
|
|
|
|
CM-xxx/A4
'ACTIVE WHEELCHAIR' symbol and 'Push to Open' text, blue. Not available on stainless steel Column(tm) switches
|
'ACTIVE WHEELCHAIR' symbol and 'Push to Open' text, blue. Not available on stainless steel Column(tm) switches
|
|
|
|
CM-xxx/4AL
WHEELCHAIR symbol and PUSH TO OPEN with ARROW left, blue. CM-7536 aluminum finish only.
|
WHEELCHAIR symbol and PUSH TO OPEN with ARROW left, blue. CM-7536 aluminum finish only.
|
|
|
|
CM-xxx/4AR
'WHEELCHAIR' symbol and 'PUSH TO OPEN' with ARROW right, blue. CM-7536 aluminum finish only.
|
'WHEELCHAIR' symbol and 'PUSH TO OPEN' with ARROW right, blue. CM-7536 aluminum finish only.
|
|
|
|
CM-xxx/20
'WHEELCHAIR' Symbol with Blue Foot Icon, Clear Label 36" Column™ aluminum finish only
|
'WHEELCHAIR' Symbol with Blue Foot Icon, Clear Label 36" Column™ aluminum finish only
|
|
|
|
CM-xxx/40
'WHEELCHAIR' Symbol and "PUSH TO OPEN" with Blue Foot Icon, Clear Label 36" Column™ aluminum finish only
|
'WHEELCHAIR' Symbol and "PUSH TO OPEN" with Blue Foot Icon, Clear Label 36" Column™ aluminum finish only
|
|
|
|
CM-xxx/80
'LOCK' Symbol Red, with Red Foot Icon, Clear Label 36" Column™ aluminum finish only
|
'LOCK' Symbol Red, with Red Foot Icon, Clear Label 36" Column™ aluminum finish only
|
|
|
|
CM-xxx/A20
'ACTIVE WHEELCHAIR' Symbol with Blue Foot Icon, Clear Label 36" Column™ aluminum finish only
|
'ACTIVE WHEELCHAIR' Symbol with Blue Foot Icon, Clear Label 36" Column™ aluminum finish only
|
|
|
|
CM-xxx/A40
'ACTIVE WHEELCHAIR' Symbol and 'PUSH TO OPEN' with Blue Foot Icon, Clear Label 36" Column™ aluminum finish only
|
'ACTIVE WHEELCHAIR' Symbol and 'PUSH TO OPEN' with Blue Foot Icon, Clear Label 36" Column™ aluminum finish only
|
|
|
| Architectural Finishes |
|
Net Cost |
|
|
CM-BRZ
Add 'BRZ' to model # for Dark Bronze finish, Aluminum only. /2 and /4 graphic option only.
|
Add 'BRZ' to model # for Dark Bronze finish, Aluminum only. /2 and /4 graphic option only.
|
|
|
|
|
CM-BLU
Add '-BLU' to model # for anodized blue finish. Aluminum only. /2 and /4 graphic option only.
|
Add '-BLU' to model # for anodized blue finish. Aluminum only. /2 and /4 graphic option only.
|
|
|
| Lazerpoint RF™ Battery Powered Wireless |
|
Net Cost |
|
|
-TX
Add suffix '-TX' to model # for CM-TX9 Lazerpoint RF(tm) Wireless Transmitter and Alkaline Battery Pack
Do not order this option with Kinetic(tm) no battery wireless switches.
|
Add suffix '-TX' to model # for CM-TX9 Lazerpoint RF(tm) Wireless Transmitter and Alkaline Battery Pack
Do not order this option with Kinetic(tm) no battery wireless switches.
|
|
|
|
|
-TXL2
Add suffix '-TX' to model # for CM-TX9 Lazerpoint RF(tm) Wireless Transmitter and Lithium Battery Pack. Recommended for low temp. applications.
Do not order this option with Kinetic(tm) no battery wireless switches.
|
Add suffix '-TX' to model # for CM-TX9 Lazerpoint RF(tm) Wireless Transmitter and Lithium Battery Pack. Recommended for low temp. applications.
Do not order this option with Kinetic(tm) no battery wireless switches.
|
|
|
| Water Tight Option |
|
Net Cost |
|
|
CM-xxx-WT
For Boot & Water Tight Coating
|
For Boot & Water Tight Coating
|
|
|
|
|
|
|
Packaging Weights & Dimensions:
|
|
|
COMPATIBLE WIRELESS
|
|
|
Click to expand section
|
|
 |
| KINETIC(TM)/LAZERPOINT(TM) RECEIVER |
|
| Kinetic(tm)/Lazerpoint(tm) Receiver |
|
Net Cost |
|
CM-RX-90
V2 Lazerpoint RF(tm) & Kinetic(tm) Compatible Single Relay Receiver
|
V2 Lazerpoint RF(tm) & Kinetic(tm) Compatible Single Relay Receiver
|
|
|
|
CM-RX-91
Basic Single Relay Receiver
|
Basic Single Relay Receiver
|
|
|
|
CM-RX-92
Full Function Dual Relay Receiver
|
Full Function Dual Relay Receiver
|
|
|
|
COMPATIBLE MOUNTING POSTS
|
|
|
Click to expand section
|
|
 |
| SWITCH BOLLARDS (POSTS) |
|
| Switch Bollards (Posts) |
|
Net Cost |
|
|
CM-42-DSU-CLR
42" Tall, prep for CM-7536 switch, 6" x 6" clear aluminum
|
42" Tall, prep for CM-7536 switch, 6" x 6" clear aluminum
|
|
|
|
|
CM-48-DSU-CLR
48" Tall, prep for CM-7536 switch, 6" x 6" clear aluminum
|
48" Tall, prep for CM-7536 switch, 6" x 6" clear aluminum
|
|
|
|
|
CM-42-DSU-BRZ
42" Tall, prep for CM-7536 switch, 6" x 6" dark bronze
|
42" Tall, prep for CM-7536 switch, 6" x 6" dark bronze
|
|
|
|
|
CM-48-DSU-BRZ
48" Tall, prep for CM-7536 switch, 6" x 6" dark bronze
|
48" Tall, prep for CM-7536 switch, 6" x 6" dark bronze
|
|
|
|
|
CM-xxx-IG
Add suffix to model # for in-ground mounting base in place of pedestal mount base normally supplied with bollard
|
Add suffix to model # for in-ground mounting base in place of pedestal mount base normally supplied with bollard
|
|
|
|
COMPATIBLE MOUNTING BOXES
|
|
|
Click to expand section
|
|
 |
| MOUNTING BOXES & ACCESSORIES |
|
| Mounting Boxes & Accessories |
|
Net Cost |
|
CM-75SB
Surface Box for CM-7536, 16-gauge steel, Powder Coat Electrical grey
|
Surface Box for CM-7536, 16-gauge steel, Powder Coat Electrical grey
|
|
|
|
CM-75SB-BK
Surface Box for CM-7536 Black,16-gauge steel, powder coat finish black
|
Surface Box for CM-7536 Black,16-gauge steel, powder coat finish black
|
|
|
|
|
Lazerpoint RF
This product series is designed for use with the industry's most reliable and easy to install wireless system!
|
|
|
