2" Piezoelectric Push/Exit Switch |
2" Piezoelectric Push/Exit Switch
|
|
CM-25, CM-26CB, CM-35 and CM-35N Series all-active switches are heavy-duty, ADA-compliant door controls. CM-25 (1-5/8" x 4-1/2") and CM-26CB/CM-35 series (2" x 4-1/2") rectangular faceplates are stainless steel, aluminum or solid brass. The CM-25 is designed to mount directly on a metal door frame or narrow surface box. The CM-35 and CM-35N Series meets new OBC requirements for activation plate size and is designed for mounting on a single gang box.
This switch is intended for connection to 'low load' access control systems. An external relay is typically required for connection to 'high loads', such as electric strikes and magnetic locks. CM-9700, CM-9710, 'SP', 'F' and 'H' models discontinued, as new 'U' and 'C' version include those message labels. Note: Not recommended for control of automatic doors.
|
|
CM-CPC1 Flush mount weather and vandal resistant cover available for this product |
COMPETITIVE MODELS
|
|
|
This product series is generally equivalent to the following competitive model(s):
|
Manufacturer |
Part Number |
Camden Part Number |
Dormakaba (RCI)
|
917
|
CM-9700U/C
|
|
|
2" Piezoelectric Push/Exit Switch |
2" Piezoelectric Push/Exit Switch
|
CM-25, CM-26CB, CM-35 and CM-35N Series all-active switches are heavy-duty, ADA-compliant door controls. CM-25 (1-5/8" x 4-1/2") and CM-26CB/CM-35 series (2" x 4-1/2") rectangular faceplates are stainless steel, aluminum or solid brass. The CM-25 is designed to mount directly on a metal door frame or narrow surface box. The CM-35 and CM-35N Series meets new OBC requirements for activation plate size and is designed for mounting on a single gang box.
|
This switch is intended for connection to 'low load' access control systems. An external relay is typically required for connection to 'high loads', such as electric strikes and magnetic locks. CM-9700, CM-9710, 'SP', 'F' and 'H' models discontinued, as new 'U' and 'C' version include those message labels. Note: Not recommended for control of automatic doors.
|
|
|
CM-CPC1 Flush mount weather and vandal resistant cover available for this product |
|
COMPETITIVE MODELS
|
|
|
This product series is generally equivalent to the following competitive model(s):
|
Manufacturer |
Part Number |
Camden Part Number |
Dormakaba (RCI)
|
917
|
CM-9700U/C
|
|
|
FEATURES |
|
SPECIFICATIONS |
|
RESOURCES |
|
|
-
Adjustable Keeper
-
No power required to operate
-
3 bilingual labels included
-
Lifetime warranty
Push Plate
-
Fully Reversable for RH/LH doors
DPDT Maintained
Holding Force: 1,200 Lbs. (545 kg.): |
12/24 VDC
|
Output: |
Solid State N/O
|
Resistance: |
"ON" Less Than 50 Ohms "OFF" Greater Than 5 MOhms
|
Switch Type: |
Momentary
|
Temp Range: |
-40°F to +180°F (-40°C to +82°C)
|
Dimensions: |
Single Gang Faceplate:
|
4-1/2" x 2-3/4" x 7/8" (114mm x 70mm x 22mm)
|
Narrow Faceplace:
|
4-1/2" x 1-3/8" x 7/8" (114mm x 35mm x 22mm)
|
|
Protection: |
IP68
|
Std. Finish: |
Brushed Aluminum
|
Push Plate |
Power Consumption: |
6 A @ 30 VDC
|
|
|
|
Single Gang Faceplate
click to expand section
|
|
Net Cost
|
|
 |
CM-9700U |
Switch with 3 English and Spanish labels (‘PUSH TO EXIT’, EMPUJE PARA ABRIR, WHEELCHAIR symbol)
EDI DATA, APPROVALS
|
|
Switch with 3 English and Spanish labels (‘PUSH TO EXIT’, EMPUJE PARA ABRIR, WHEELCHAIR symbol)
|
EDI DATA APPROVALS
|
|
|
|
|
Dimensions: 3"L x 5"W x 2"H
Weight: 0.54lbs.
UPC: 670454171962
Country of Origin: US
|
|
 |
CM-9700C |
Switch with 3 English and French labels (‘PUSH TO EXIT’, POUSSEZ POUR SORTIR, WHEELCHAIR symbol)
EDI DATA, APPROVALS
|
|
Switch with 3 English and French labels (‘PUSH TO EXIT’, POUSSEZ POUR SORTIR, WHEELCHAIR symbol)
|
EDI DATA APPROVALS
|
|
|
|
|
Dimensions: 3"L x 5"W x 2"H
Weight: 0.54lbs.
UPC: 670454171955
Country of Origin: US
|
|
Narrow Faceplate
click to expand section
|
|
Net Cost
|
|
 |
CM-9710U |
Switch with 3 English and Spanish labels (‘PUSH TO EXIT’, EMPUJE PARA ABRIR, WHEELCHAIR symbol)
EDI DATA, APPROVALS
|
|
Switch with 3 English and Spanish labels (‘PUSH TO EXIT’, EMPUJE PARA ABRIR, WHEELCHAIR symbol)
|
EDI DATA APPROVALS
|
|
|
|
|
Dimensions: 3"L x 5"W x 2"H
Weight: 0.3lbs.
UPC: 670454171986
Country of Origin: US
|
|
 |
CM-9710C |
Switch with 3 English and French labels (‘PUSH TO EXIT’, POUSSEZ POUR SORTIR, WHEELCHAIR symbol)
EDI DATA, APPROVALS
|
|
Switch with 3 English and French labels (‘PUSH TO EXIT’, POUSSEZ POUR SORTIR, WHEELCHAIR symbol)
|
EDI DATA APPROVALS
|
|
|
|
|
Dimensions: 3"L x 5"W x 2"H
Weight: 0.3lbs.
UPC: 670454171979
Country of Origin: US
|
|
|
new option
|
|
Packaging Weights & Dimensions:
|
|
COMPATIBLE MOUNTING BOXES
|
|
|
Click to expand section
|
|
 |
MOUNTING BOXES & ACCESSORIES |
|
Mounting Boxes & Accessories: Narrow/Jamb |
|
Net Cost |
|
CM-23
Surface Box, Standard Depth Narrow/Jamb boxes for 9710 series switches
|
Surface Box, Standard Depth Narrow/Jamb boxes for 9710 series switches
|
|
|
Mounting Boxes & Accessories: Single Gang |
|
Net Cost |
|
CM-34BL
Surface Box, Standard Depth. Double wall Single Gang boxes for 9700 series switches
|
Surface Box, Standard Depth. Double wall Single Gang boxes for 9700 series switches
|
|
|
|
CM-34AL
Surface Box, Standard Depth, threaded conduit entry. Heavy duty cast aluminum Single Gang boxes for 9700 series switches
|
Surface Box, Standard Depth, threaded conduit entry. Heavy duty cast aluminum Single Gang boxes for 9700 series switches
|
|
|
|
CM-CPC1
Vandal and weather resistant clear lift cover Single Gang boxes for 9700 series switches
|
Vandal and weather resistant clear lift cover Single Gang boxes for 9700 series switches
|
|
|
|
|
 |
