| CM-45/2, 4-1/2" Sq. (Concealed Screws) |
CM-45/2, 4-1/2" Sq. (Concealed Screws)
|
|
CM-45 (concealed screws) and CM-46 Series (exposed screws) 4-1/2" square push plate switches mount to standard single/double gang electrical boxes. The SPDT (and optional DPDT) switches are rated 15 amps @ 30 VDC. Push switches are offered with different graphics in various architectural finishes. Weather resistant and water tight configurations also available.
NEW: CAMDEN PUSH PLATE SWITCHES NOW FEATURE STANDARD WATER RESISTANCE - NO NEED TO SELECT 'WR' OPTION! Note: Optional architectural finishes available for CM-45 Series only by special order. Purchase order cannot be cancelled following issue of order confirmation and product cannot be returned for credit. A min. of 14 business days is required for production.
Architectural Finishes:
CM-45 Series switches with architectural finish
only available with /1, /2, /3, /4, /8 graphic options
|
|
|
| CM-46/4, 4-1/2" Sq. (Exposed Screws) |
|
|
|
| CM-46CB/4, 4-1/2" Sq. Blue (Exposed Screws) |
|
|
|
| Blog Post | New Accessibility Symbol |
|
|
|
| Available inKinetic(tm) Models |
|
COMPETITIVE MODELS
|
|
|
|
This product series is generally equivalent to the following competitive model(s):
|
| Manufacturer |
Part Number |
Camden Part Number |
|
Alarm Controls
|
PD1-111
|
CM-45, CM-xxx/3
|
|
|
PD1-134
|
CM-45, CM-xxx/4
|
|
|
PD2-121
|
CM-45, CM-xxx/8D, CM-xxx-DP
|
|
|
PD2-134
|
CM-45, CM-xxx/4, CM-xxx-DP
|
|
|
PD5-433
|
CM-46CB, CM-xxx/4, CM-xxx-DP
|
|
BEA
|
10PBS
|
CM-45, CM-xxx/3
|
|
|
10PBS1
|
CM-45, CM-xxx/4
|
|
|
10PBS10
|
CM-45, CM-xxx/1
|
|
|
10PBS1AL
|
CM-45, CM-xxx/A4
|
|
|
10PBS1B
|
CM-46CB, CM-xxx/4
|
|
|
10PBS1BB
|
CM-45, CM-xxx/4, CM-xxx-PB
|
|
|
10PBS1SB
|
CM-45, CM-xxx/4, CM-xxx-SB
|
|
|
10PBSE
|
CM-45, CM-xxx/7
|
|
|
10PBSLL
|
CM-45, CM-xxx/2
|
|
Dormakaba (RCI)
|
946-H45MOX32D
|
CM-45, CM-xxx/2
|
|
|
946-H45MOXBLU
|
CM-46CB, CM-xxx/2
|
|
|
946-HP45MOX32D
|
CM-45, CM-xxx/4
|
|
|
946-HP45MOXBLU
|
CM-46CB, CM-xxx/4
|
|
|
946-P45MOX32D
|
CM-45, CM-xxx/3
|
|
MS Sedco
|
59-H
|
CM-46CB, CM-xxx/4
|
|
|
59-HSS
|
CM-46, CM-xxx/4
|
|
|
59-P
|
CM-46, CM-xxx/3
|
|
|
59-W
|
CM-46CB, CM-xxx/2
|
|
|
59-WSS
|
CM-46, CM-xxx/2
|
|
Wikk
|
4X4-1
|
CM-45, CM-xxx/1
|
|
|
4X4-11
|
CM-45, CM-xxx/7
|
|
|
4X4-2
|
CM-45, CM-xxx/3
|
|
|
4X4-3
|
CM-45, CM-xxx/4
|
|
|
4X4-3AL
|
CM-45, CM-xxx/4AL
|
|
|
4X4-3AR
|
CM-45, CM-xxx/4AR
|
|
|
4X4-5
|
CM-45, CM-xxx/2
|
|
|
| CM-45/2, 4-1/2" Sq. (Concealed Screws) |
CM-45/2, 4-1/2" Sq. (Concealed Screws)
|
CM-45 (concealed screws) and CM-46 Series (exposed screws) 4-1/2" square push plate switches mount to standard single/double gang electrical boxes. The SPDT (and optional DPDT) switches are rated 15 amps @ 30 VDC. Push switches are offered with different graphics in various architectural finishes. Weather resistant and water tight configurations also available.
NEW: CAMDEN PUSH PLATE SWITCHES NOW FEATURE STANDARD WATER RESISTANCE - NO NEED TO SELECT 'WR' OPTION! Note: Optional architectural finishes available for CM-45 Series only by special order. Purchase order cannot be cancelled following issue of order confirmation and product cannot be returned for credit. A min. of 14 business days is required for production.
Architectural Finishes:
CM-45 Series switches with architectural finish
only available with /1, /2, /3, /4, /8 graphic options
|
|
|
|
|
|
|
| CM-46/4, 4-1/2" Sq. (Exposed Screws) |
|
|
|
|
| CM-46CB/4, 4-1/2" Sq. Blue (Exposed Screws) |
|
|
|
|
| Blog Post | New Accessibility Symbol |
|
|
|
|
| Available inKinetic(tm) Models |
|
|
COMPETITIVE MODELS
|
|
|
|
This product series is generally equivalent to the following competitive model(s):
|
| Manufacturer |
Part Number |
Camden Part Number |
|
Alarm Controls
|
PD1-111
|
CM-45, CM-xxx/3
|
|
|
PD1-134
|
CM-45, CM-xxx/4
|
|
|
PD2-121
|
CM-45, CM-xxx/8D, CM-xxx-DP
|
|
|
PD2-134
|
CM-45, CM-xxx/4, CM-xxx-DP
|
|
|
PD5-433
|
CM-46CB, CM-xxx/4, CM-xxx-DP
|
|
BEA
|
10PBS
|
CM-45, CM-xxx/3
|
|
|
10PBS1
|
CM-45, CM-xxx/4
|
|
|
10PBS10
|
CM-45, CM-xxx/1
|
|
|
10PBS1AL
|
CM-45, CM-xxx/A4
|
|
|
10PBS1B
|
CM-46CB, CM-xxx/4
|
|
|
10PBS1BB
|
CM-45, CM-xxx/4, CM-xxx-PB
|
|
|
10PBS1SB
|
CM-45, CM-xxx/4, CM-xxx-SB
|
|
|
10PBSE
|
CM-45, CM-xxx/7
|
|
|
10PBSLL
|
CM-45, CM-xxx/2
|
|
Dormakaba (RCI)
|
946-H45MOX32D
|
CM-45, CM-xxx/2
|
|
|
946-H45MOXBLU
|
CM-46CB, CM-xxx/2
|
|
|
946-HP45MOX32D
|
CM-45, CM-xxx/4
|
|
|
946-HP45MOXBLU
|
CM-46CB, CM-xxx/4
|
|
|
946-P45MOX32D
|
CM-45, CM-xxx/3
|
|
MS Sedco
|
59-H
|
CM-46CB, CM-xxx/4
|
|
|
59-HSS
|
CM-46, CM-xxx/4
|
|
|
59-P
|
CM-46, CM-xxx/3
|
|
|
59-W
|
CM-46CB, CM-xxx/2
|
|
|
59-WSS
|
CM-46, CM-xxx/2
|
|
Wikk
|
4X4-1
|
CM-45, CM-xxx/1
|
|
|
4X4-11
|
CM-45, CM-xxx/7
|
|
|
4X4-2
|
CM-45, CM-xxx/3
|
|
|
4X4-3
|
CM-45, CM-xxx/4
|
|
|
4X4-3AL
|
CM-45, CM-xxx/4AL
|
|
|
4X4-3AR
|
CM-45, CM-xxx/4AR
|
|
|
4X4-5
|
CM-45, CM-xxx/2
|
| |
|
-
ADA Compliant
-
3 year warranty
-
4 stud switch design and rubber dampers for quieter operation
-
CM-45:
-
Hidden mounting screws
-
Stainless steel construction
-
CM-46CB:
-
Exposed screws for easy maintenance
-
Aluminum construction
| Voltage: |
12/24V AC/DC
|
| Switch Type: |
Momentary
|
| Contact Type: |
SPDT Form 'C'
|
| Current Rating: |
15 A @ 30 VDC
|
| Mounting: |
Single or Double Gang
|
| Dimensions: |
|
CM-45,
CM-46:
|
4-1/2" x 4-1/2" x 1-1/4"
(114mm x 114mm x 32mm)
|
| |
| Std. Finish: |
|
CM-45,
CM-46:
|
US32 / 630
|
|
CM-46CB:
|
Blue Paint
|
| |
|
|
MODELS
|
|
Click to configure switch model
|
|
|
|
WIZARD
|
| SELECT MODEL |
 |
|
|
|
|
WIZARD
|
| SELECT MODEL |
|
|
|
|
Wired 4-1/2" Square
click to expand section
|
|
Net Cost
|
|
CM-45
4-1/2" Square Push Plate Switch, Concealed Screws
EDI DATA, APPROVALS
|
|
4-1/2" Square Push Plate Switch, Concealed Screws
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: 1.25"L x 6.25"W x 6.25"H
Weight: 0.85lbs.
UPC:NA
|
|
CM-46
4-1/2" Square Push Plate Switch, Exposed Screws Not available with Architectural Finishes
EDI DATA, APPROVALS
|
|
4-1/2" Square Push Plate Switch, Exposed Screws Not available with Architectural Finishes
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: 1.25"L x 6.25"W x 6.25"H
Weight: 0.95lbs.
UPC:NA
|
|
CM-46CB
4-1/2” Square Blue Push Plate Switch, White Graphics, Exposed Screws. Graphic Options: '/1' (blank), '/2' (Wheelchair) & '/4' (Wheelchair and Push to Open) only
EDI DATA, APPROVALS
|
|
4-1/2” Square Blue Push Plate Switch, White Graphics, Exposed Screws. Graphic Options: '/1' (blank), '/2' (Wheelchair) & '/4' (Wheelchair and Push to Open) only
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: 1.25"L x 6.25"W x 6.25"H
Weight: 0.85lbs.
|
| |
|
4-1/2" Square, Kinetic(tm) No Battery Wireless
click to expand section
|
|
Net Cost
|
|
CM-45K
4-1/2" Square Push Plate Switch, Concealed Screws, w/ no-battery Kinetic wireless transmitter
EDI DATA, APPROVALS
|
|
4-1/2" Square Push Plate Switch, Concealed Screws, w/ no-battery Kinetic wireless transmitter
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: 1.25"L x 6.25"W x 6.25"H
Weight: 0.85lbs.
UPC:NA
|
|
CM-46K
4-1/2" Square Push Plate Switch, Exposed Screws, w/ no-battery Kinetic wireless transmitter Not available with Architectural Finishes
EDI DATA, APPROVALS
|
|
4-1/2" Square Push Plate Switch, Exposed Screws, w/ no-battery Kinetic wireless transmitter Not available with Architectural Finishes
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: 1.75"L x 6.25"W x 6.25"H
Weight: 0.85lbs.
UPC:NA
|
|
CM-46CBK
4-1/2” Square Blue Push Plate Switch, Exposed Screws, w/ no-battery Kinetic wireless transmitter
EDI DATA, APPROVALS
|
|
4-1/2” Square Blue Push Plate Switch, Exposed Screws, w/ no-battery Kinetic wireless transmitter
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: 1.75"L x 6.25"W x 6.25"H
Weight: 0.85lbs.
UPC:NA
|
| |
|
|
OPTIONS & FINISHES
|
|
|
Click to expand section
|
|
|
|
|
WIZARD
|
| SELECT OPTIONS |
|
|
|
|
|
WIZARD
|
|
SELECT OPTIONS
|
|
|
|
|
|
WIZARD
|
| SELECT MODEL ABOVE |
 |
|
|
|
|
WIZARD
|
| SELECT OPTIONS |
|
|
|
|
 |
| FACEPLATE GRAPHIC OPTIONS |
 |
| WEATHER RESISTANT OPTIONS |
 |
| CONTACT OPTIONS |
 |
| ARCHITECTURAL FINISH OPTIONS |
|
| Faceplate Graphic Options |
|
Net Cost |
|
CM-xxx/1
'BLANK' faceplate
|
'BLANK' faceplate
|
|
|
|
CM-xxx/2
'WHEELCHAIR' symbol, blue
|
'WHEELCHAIR' symbol, blue
|
|
|
|
CM-xxx/2AL
WHEELCHAIR symbol with ARROW left, blue graphics
|
WHEELCHAIR symbol with ARROW left, blue graphics
|
|
|
|
CM-xxx/2AR
WHEELCHAIR symbol with ARROW right, blue graphics
|
WHEELCHAIR symbol with ARROW right, blue graphics
|
|
|
|
CM-xxx/A2
'ACTIVE WHEELCHAIR' symbol, blue (CM-45 series only)
|
'ACTIVE WHEELCHAIR' symbol, blue (CM-45 series only)
|
|
|
|
CM-xxx/3
'PUSH TO OPEN', black graphics
|
'PUSH TO OPEN', black graphics
|
|
|
|
CM-xxx/3F
'POUSSEZ POUR OUVRIR', black graphics
|
'POUSSEZ POUR OUVRIR', black graphics
|
|
|
|
CM-xxx/4
'WHEELCHAIR' symbol and 'PUSH TO OPEN', blue
|
'WHEELCHAIR' symbol and 'PUSH TO OPEN', blue
|
|
|
|
CM-xxx/4F
'WHEELCHAIR' and 'POUSSEZ POUR OUVRIR', black graphics
|
'WHEELCHAIR' and 'POUSSEZ POUR OUVRIR', black graphics
|
|
|
|
CM-xxx/4AL
WHEELCHAIR symbol with ARROW left, blue graphics
|
WHEELCHAIR symbol with ARROW left, blue graphics
|
|
|
|
CM-xxx/4AR
'WHEELCHAIR' symbol and 'PUSH TO OPEN' with ARROW right, blue graphics
|
'WHEELCHAIR' symbol and 'PUSH TO OPEN' with ARROW right, blue graphics
|
|
|
|
CM-xxx/A4
'ACTIVE WHEELCHAIR' symbol and 'Push to Open' text, blue (CM-45 series only)
|
'ACTIVE WHEELCHAIR' symbol and 'Push to Open' text, blue (CM-45 series only)
|
|
|
|
CM-xxx/8
'PUSH TO LOCK', black
|
'PUSH TO LOCK', black
|
|
|
|
CM-xxx/8B
'LOCK SYMBOL' and 'PUSH TO LOCK', Red text
|
'LOCK SYMBOL' and 'PUSH TO LOCK', Red text
|
|
|
|
CM-xxx/8D
'PUSH TO LOCK DOOR', black
|
'PUSH TO LOCK DOOR', black
|
|
|
|
CM-xxx/8F
'POUSSEZ POUR VERROUILLER', black text
|
'POUSSEZ POUR VERROUILLER', black text
|
|
|
| Weatherproof Options |
|
Net Cost |
|
|
CM-xxx-WT
boot and water tight coating Add 'WT' to product #
|
boot and water tight coating Add 'WT' to product #
|
|
|
| Contact Options |
|
Net Cost |
|
|
CM-xxx-DP
DPDT switch instead of SPDT switch
|
DPDT switch instead of SPDT switch
|
|
|
| Architectural Finishes (Only Available with CM-45 /1, /2, /3, /4, /8 Graphic Options) |
|
Net Cost |
|
CM-xxx-SB
satin brass finish (US4 / 606)
|
satin brass finish (US4 / 606)
|
|
|
|
CM-xxx-OB
oil rub bronze finish (US10B / 613)
|
oil rub bronze finish (US10B / 613)
|
|
|
|
CM-xxx-PB
polished brass (US3 / 605)
|
polished brass (US3 / 605)
|
|
|
|
CM-xxx-AB
antique brass finish (US5 / 609)
|
antique brass finish (US5 / 609)
|
|
|
|
|
|
|
Packaging Weights & Dimensions:
|
|
|
COMPATIBLE MOUNTING BOXES
|
|
|
Click to expand section
|
|
 |
| MOUNTING BOXES & ACCESSORIES |
 |
| SWITCH BOLLARDS (POSTS) |
|
| Mounting Boxes & Accessories: Double Gang |
|
Net Cost |
|
CM-43CBL
Surface Box, Standard Depth, provision for wireless. Double wall, black polymer (ABS). Flame/Impact resistant, 4-1/2"W x 4-1/2"H x 2"D.
|
Surface Box, Standard Depth, provision for wireless. Double wall, black polymer (ABS). Flame/Impact resistant, 4-1/2"W x 4-1/2"H x 2"D.
|
|
|
|
CM-43LP
Surface Box, Shallow depth, provision for wireless, black polymer (ABS) flame/impact resistant, 5" x 5" x 1-3/8". For use with CM-45/46 push plate switches.
Add suffix ‘B’ when used with CM-2520 double gang vestibule switches
|
Surface Box, Shallow depth, provision for wireless, black polymer (ABS) flame/impact resistant, 5" x 5" x 1-3/8". For use with CM-45/46 push plate switches.
Add suffix ‘B’ when used with CM-2520 double gang vestibule switches
|
|
|
|
|
CM-43GMK
Glass Mount Kit for CM-43LP Box
|
Glass Mount Kit for CM-43LP Box
|
|
|
|
CM-540B
Surface Box, Shallow Depth. Flame and Impact resistant black polymer (ABS) 4-13/16" x 4-13/16" x 5/8"
|
Surface Box, Shallow Depth. Flame and Impact resistant black polymer (ABS) 4-13/16" x 4-13/16" x 5/8"
|
|
|
|
CM-660
6-1/2" Dress plate, Cover for double gang or 4" square flush box, Heavy gauge stainless steel
|
6-1/2" Dress plate, Cover for double gang or 4" square flush box, Heavy gauge stainless steel
|
|
|
|
CM-49C
Adapter plate for mounting on double gang or 4" Square box 4" x 1/16"
|
Adapter plate for mounting on double gang or 4" Square box 4" x 1/16"
|
|
|
|
|
CM-43G
Gasket for CM-43CBL and CM-63CBL Boxes
|
Gasket for CM-43CBL and CM-63CBL Boxes
|
|
|
|
CM-55CBL
Flush box, Standard Depth, flame/Impact resistant black polymer (ABS) 6-1/2"W x 6 1/2"H x 2". For use with CM-45/46 Series
|
Flush box, Standard Depth, flame/Impact resistant black polymer (ABS) 6-1/2"W x 6 1/2"H x 2". For use with CM-45/46 Series
|
|
|
| Switch Bollards (Posts): Clear Aluminum |
|
Net Cost |
|
|
CM-42-CSU-CLR
42" Tall, No switch prep, 6" x 6" clear aluminum
|
42" Tall, No switch prep, 6" x 6" clear aluminum
|
|
|
|
CM-42-BSU-CLR
42" Tall, (36" Switch Height) Single gang prep, 6" x 6" clear aluminum
|
42" Tall, (36" Switch Height) Single gang prep, 6" x 6" clear aluminum
|
|
|
|
|
CM-48-BSU-CLR
48" Tall, (42" Switch Height) Single gang prep, 6" x 6" clear aluminum
|
48" Tall, (42" Switch Height) Single gang prep, 6" x 6" clear aluminum
|
|
|
| Switch Bollards (Posts): Dark Bronze |
|
Net Cost |
|
|
CM-42-CSU-BRZ
42" Tall, No switch prep, 6" x 6" dark bronze finish
|
42" Tall, No switch prep, 6" x 6" dark bronze finish
|
|
|
|
CM-42-BSU-BRZ
42" Tall, (36" Switch Height) Single gang prep, 6" x 6" dark bronze finish
|
42" Tall, (36" Switch Height) Single gang prep, 6" x 6" dark bronze finish
|
|
|
|
|
CM-48-BSU-BRZ
48" Tall, (42" Switch Height) Single gang prep, 6" x 6" dark bronze finish
|
48" Tall, (42" Switch Height) Single gang prep, 6" x 6" dark bronze finish
|
|
|
| Switch Bollards (Posts): Mill Finish |
|
Net Cost |
|
|
CM-42-CSU-MIL
42" Tall, No switch prep, 6" x 6" mill finish
|
42" Tall, No switch prep, 6" x 6" mill finish
|
|
|
|
|
CM-42-BSU-MIL
42" Tall, (36" Switch Height) Single gang prep, 6" x 6" mill finish
|
42" Tall, (36" Switch Height) Single gang prep, 6" x 6" mill finish
|
|
|
|
|
CM-48-BSU-MIL
48"Tall, (42" Switch Height) Single gang prep, 6" x 6" mill finish
|
48"Tall, (42" Switch Height) Single gang prep, 6" x 6" mill finish
|
|
|
| Switch Bollards (Posts): Stainless Steel |
|
Net Cost |
|
CM-42-BSU-SS
42” Tall, Single Gang Switch Prep, 6” x 6” stainless steel
|
42” Tall, Single Gang Switch Prep, 6” x 6” stainless steel
|
|
|
|
|
CM-48-BSU-SS
48” Tall, Single Gang Switch Prep, 6” x 6” stainless steel
|
48” Tall, Single Gang Switch Prep, 6” x 6” stainless steel
|
|
|
|
|
Lazerpoint RF
This product series is designed for use with the industry's most reliable and easy to install wireless system!
|
|
|
