Camden CX-PS Series power supplies are available in a range of 1.7 Amp, 3 Amp, and 6 Amp models and are ideal for powering electric strikes and magnetic locks in access control, door control, and other low-voltage applications.
CX-PS Series power supplies are UL 294 and ULC S533, and 60839-11-1 listed. These models offer over current protected outputs, battery charger, up to 8 output circuits, and heavy gauge locking metal cabinets.
|
|
|
| FEATURES |
|
SPECIFICATIONS |
|
RESOURCES |
|
|
- CX-PS150UL - Latching fire alarm tie-in with reset - 12 or 24 VDC selectable 1.7 Amp output- 12 or 24 VDC 200mA auxiliary output- AC and DC power and status indicators- Short circuit and terminal protection- Battery charger (500mA)- 120 VAC power input- Metal enclosure accommodates (1) 4 Ah. battery (not included)
- CX-PS300UL / CX-PS600UL - Latching fire alarm tie-in with reset- 12 or 24 VDC selectable outputs: CX-PS300: (4) outputs, 3 Amp max CX-PS600: (8) outputs, 6 Amp max- AC power and status indicators- Short circuit and terminal protection- Battery charger (1.5 Amp)- 120/240 VAC power input- Low battery, battery disconnect, and battery charger trouble monitoring- Metal enclosure accommodates (2) 12Ah. batteries (not included)
| Voltage: |
CX-PS150UL: 120 VAC
CX-PS300UL / 600UL: 120/240 VAC |
| Output Voltage: |
12/24 VDC |
| Output Power: |
CX-PS150UL: (2) 1.7 Amps, 500mA Battery Charger
CX-PS300UL: (4) 3 Amps, 1.5 Amp Battery Charger
CX-PS600UL: (8) 6 Amps, 1.5 Amp Battery Charger
|
| Output Protection: |
Short Circuit Protection |
| Battery Charger Monitor: |
CX-PS300 / 600UL: Battery Load Test Every 48 Hours
|
| Enclosure Accomodates: |
CX-PS150UL: (1) 12 VDC / 4 Ah Battery
CX-PS300UL/600UL: CX-(2) 12 VDC / 12 Ah Batteries |
| Dimensions: |
CX-PS150UL:
9-1/8"H x 8"W x 3-1/2"D (231 x 204 x 89mm)
CX-PS300UL / 600UL:
17-1/2"H x 13"W x 4-5/16"D (445 x 330 x 110mm) |
|
Manuals
|
| CX-PS150UL Power Supply Manual |
pdf |
0.50 |
DOWNLOAD
|
| CX-PS150UL Power Supply Manual_FR |
pdf |
0.40 |
DOWNLOAD
|
| CX-PS300UL Power Supply Manual |
pdf |
0.67 |
DOWNLOAD
|
| CX-PS300UL Power Supply Manual_FR |
pdf |
0.68 |
DOWNLOAD
|
| CX-PS600UL Power Supply Manual |
pdf |
0.68 |
DOWNLOAD
|
| CX-PS600UL Power Supply Manual_FR |
pdf |
0.71 |
DOWNLOAD
|
|
Spec Sheets
|
| CX-PS Series Spec Sheet |
pdf |
1.92 |
DOWNLOAD
|
|
High Resolution Images
|
| CX-PS150UL |
png |
3.68 |
DOWNLOAD
|
| CX-PS300UL |
png |
2.74 |
DOWNLOAD
|
| CX-PS600UL |
png |
2.74 |
DOWNLOAD
|
| CX-PS150UL Interior |
png |
4.49 |
DOWNLOAD
|
| CX-PS300UL Interior |
png |
5.73 |
DOWNLOAD
|
| CX-PS600UL Interior |
png |
2.94 |
DOWNLOAD
|
|
Discontinued Model Resources
|
| CX-PS10UL Manual |
pdf |
0.09 |
DOWNLOAD
|
| CX-PS30/60UL Manual |
pdf |
0.31 |
DOWNLOAD
|
|
|
|
Power Supplies
 click to expand section
|
|
Net Cost
|
|
CX-PS150UL
1.7 Amp Power Supply with (2) Fused Outputs (2 Amp) 12/24VDC two outputs +300mA auxiliary output
EDI DATA, APPROVALS
|
|
1.7 Amp Power Supply with (2) Fused Outputs (2 Amp) 12/24VDC two outputs +300mA auxiliary output
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: 10.5"L x 8.75"W x 4"H
Weight: 7.75lbs.
UPC:670454215659
|
|
CX-PS300UL
3 Amp Power Supply with (4) Fused Outputs (2 Amp) 12/24 3 Amp max with 4 ECB output fused at 2A max
EDI DATA, APPROVALS
|
|
3 Amp Power Supply with (4) Fused Outputs (2 Amp) 12/24 3 Amp max with 4 ECB output fused at 2A max
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: 19"L x 13.5"W x 4.75"H
Weight: 13.25lbs.
UPC:670454215666
|
|
CX-PS600UL
6 Amp Power Supply with (8) Fused Outputs (2 Amp) 12/24 6 amp max with 8 ECB output fused at 2A max
EDI DATA, APPROVALS
|
|
6 Amp Power Supply with (8) Fused Outputs (2 Amp) 12/24 6 amp max with 8 ECB output fused at 2A max
|
EDI DATA
APPROVALS
|
|
|
|
| |
Dimensions: 19"L x 13.5"W x 4.75"H
Weight: 13.25lbs.
UPC:670454215673
|
| |
|
