Series 20
BHMA Grade 2
classification sales literature images manuals related products
Features
• Centerline Latch Entry, 5/8" - 3/4" Latch Projection
• UL 1034 Burglary Listed
• Fail Safe or Fail Secure Models
• Reversible for RH/LH doors
• Continuous Duty Operation (DC)
ELECTRIC STRIKES With INTEGRAL FACE PLATES
BHMA Grade 2
CX-EU2015 Fail Safe 12VDC - ANSI Square (4 7/8" x 1 1/4") faceplate  UL Listed
CX-EU2025 Fail Safe 12VDC - ANSI Round (4 7/8" x 1 1/4") faceplate  UL Listed
CX-EU2035 Fail Safe 12VDC - Hollow Metal door (6 7/8 x 1 1/4") faceplate  UL Listed
CX-EU2045 Fail Safe 12VDC - Wood Door (7 15/16" x 1 7/16") faceplate  UL Listed
CX-EU2018 Fail Safe 24VDC - ANSI Square (4 7/8" x 1 1/4") faceplate  UL Listed
CX-EU2028 Fail Safe 24VDC - ANSI Round (4 7/8" x 1 1/4") faceplate  UL Listed
CX-EU2038 Fail Safe 24VDC - Hollow Metal door (6 7/8 x 1 1/4") faceplate  UL Listed
CX-EU2048 Fail Safe 24VDC - Wood Door (7 15/16" x 1 7/16") faceplate  UL Listed
CX-EL2011 Fail Secure, 8-16V AC/DC - ANSI Square (4 7/8" x 1 1/4") faceplate  UL Listed
CX-EL2021 Fail Secure, 8-16V AC/DC - ANSI Round (4 7/8" x 1 1/4") faceplate  UL Listed
CX-EL2031 Fail Secure, 8-16V AC/DC - Hollow Metal door (6 7/8 x 1 1/4") faceplate  UL Listed
CX-EL2041 Fail Secure, 8-16V AC/DC - Wood Door (7 15/16" x 1 7/16") faceplate  UL Listed
CX-EL2015 Fail Secure 12VDC - ANSI Square (4 7/8" x 1 1/4") faceplate  UL Listed
CX-EL2025 Fail Secure 12VDC - ANSI Round (4 7/8" x 1 1/4") faceplate  UL Listed
CX-EL2035 Fail Secure 12VDC - Hollow Metal door (6 7/8 x 1 1/4") faceplate  UL Listed
CX-EL2045 Fail Secure 12VDC - Wood Door (7 15/16" x 1 7/16") faceplate  UL Listed
CX-EL2018 Fail Secure 24VDC - ANSI Square (4 7/8" x 1 1/4") faceplate  UL Listed
CX-EL2028 Fail Secure 24VDC - ANSI Round (4 7/8" x 1 1/4") faceplate  UL Listed
CX-EL2038 Fail Secure 24VDC - Hollow Metal door (6 7/8 x 1 1/4") faceplate  UL Listed
CX-EL2048 Fail Secure 24VDC - Wood Door (7 15/16" x 1 7/16") faceplate  UL Listed
ELECTRIC STRIKES
BHMA Grade 2
CX-EU2005 Fail Safe 12VDC  UL Listed
CX-EU2008 Fail Safe 24VDC  UL Listed
CX-EL2001 Fail Secure 8-16V AC/DC  UL Listed
CX-EL2005 Fail Secure 12VDC  UL Listed
CX-EL2008 Fail Secure 24VDC  UL Listed
FACE PLATES FOR STRIKES 3 of 5 click for more click for fewer
Faceplate Finish Options
CX-XXXDUR Duranodic Faceplate Finish

Faceplate Options
CX-ESP-1 ANSI Square, 4 7/8" x 1 1/4", stainless steel
CX-ESP-2 ANSI Round, 4 7/8" x 1 1/4" , stainless steel
CX-ESP-3 Hollow Metal Door, 6 7/8" x 1 1/4", stainless steel
CX-ESP-4 Wood Door, 7 15/16" x 1 7/16"
Product Materials
Sales Literature
Electric Strikes_Presentation pdf 0.91MB DOWNLOAD
ElectricStrikes-SERIES 20_SpecSheet_Sept09 pdf 0.92MB DOWNLOAD
SaleSheet pdf 1.74MB DOWNLOAD

Images
Series 20 Strike tiff 10.33MB DOWNLOAD

Manuals
20 + 30 Series_Installation Instructions pdf 1.01MB DOWNLOAD
