Series 40
Light Duty
| • |
Economy Strike
|
| • |
Reversible for RH/LH doors
|
| • |
Centerline Latch Entry, 5/8" - 3/4 Latch Projection
|
|
| • |
Adjustable Keeper
|
| • |
Continuous Duty Operation (DC)
|
| • |
Fail Secure
|
|
|
|
|
ELECTRIC STRIKES With INTEGRAL FACE PLATES
|
|
CX-EL4011 |
|
Fail Secure, 8-16V AC/DC - ANSI Square, 4 7/8 x 1 1/4"
|
|
|
|
|
CX-EL4021 |
|
Fail Secure, 8-16V AC/DC - ANSI Round 4 7/8 x 1 1/4"
|
|
|
|
|
CX-EL4031 |
|
Fail Secure 8-16V AC/DC - Hollow Metal Door 6 7/8 x 1 7/16"
|
|
|
|
|
CX-EL4041 |
|
Fail Secure 8-16V AC/DC - Wood Door 7 15/16 x 1 7/16"
|
|
|
|
|
CX-EL4015 |
|
Fail Secure 12VDC - ANSI Square, 4 7/8 x 1 1/4"
|
|
|
|
|
CX-EL4025 |
|
Fail Secure 12VDC - ANSI Round 4 7/8 x 1 1/4"
|
|
|
|
|
CX-EL4035 |
|
Fail Secure 12VDC - Hollow Metal Doors 6 7/8 x 1 1/4"
|
|
|
|
|
CX-EL4045 |
|
Fail Secure 12VDC - Wood Door 7 15/16 x 1 7/16"
|
|
|
|
|
CX-EL4018 |
|
Fail Secure 24VDC - ANSI Square, 4 7/8 x 1 1/4"
|
|
|
|
|
CX-EL4028 |
|
Fail Secure 24VDC - ANSI Round 4 7/8 x 1 1/4"
|
|
|
|
|
CX-EL4038 |
|
Fail Secure 24VDC - Hollow Metal Doors 6 7/8 x 1 1/4"
|
|
|
|
|
CX-EL4048 |
|
Fail Secure 24VDC - Wood Door 7 15/16 x 1 7/16"
|
|
|
|
|
|
|
CX-EL4001 |
|
Fail Secure, 8 -16V AC/DC
|
|
|
|
|
CX-EL4005 |
|
Fail Secure 12VDC
|
|
|
|
|
CX-EL4008 |
|
Fail Secure 24VDC
|
|
|
|
|
|
Faceplate Options
|
|
|
CX-ESP1 |
|
ANSI Square, 4 7/8" X 1 1/4"
|
|
|
|
|
CX-ESP2 |
|
ANSI Round, 4 7/8" X 1 1/4"
|
|
|
|
|
CX-ESP3 |
|
Holow Metal Door, 6 7/8" X 1 1/4"
|
|
|
|
|
CX-ESP4 |
|
Wood Door, 7 15/16" X 1 7/16"
|
|
|
Faceplate Finish Options
|
|
|
CX-XXXDUR |
|
Duranodic Faceplate Finish
|
|
|
|
|
|
Related Products
|
click for more
click for fewer
|
|
Series 20
|
Pre Load Electric Strikes
. . . more
Pre Load Electric Strikes
. . .
Series 20 Pre Load electric strikes offer the highest pre load rating,12/24V AC/DC operation, adjustable keeper, fail safe/fail secure operation, and latch monitoring. Latch cavity accommodates cylindrical locksets with 1/2" to 5/8" projection.
. . . less
|
|
|
Series 10/18 (EZ Fit)
|
BHMA Grade 1
. . . more
BHMA Grade 1
. . .
Designed for heavy duty applications, the all-in-one Series 10 and 18 strikes offer dual voltage, field selectable fail secure, fail safe operation. The Series 18 model features EZ Fit installation in any standard ANSI strike plate door frame opening.
. . . less
|
|
|
Series 14
|
BHMA Grade 1 Fire Rated
. . . more
BHMA Grade 1 Fire Rated
. . .
BMHA Grade 1 heavy duty tested to 1.5 million cycles. Dual voltage and field selectable fail safe/fail secure. CX-EL1400/10/20/30/40 electric strikes are UL1034 and Warnock Hersey fire rated. CX-EL1450A/AL electric strikes are UL10C fire rated for installation in fire rated doors without cutting or drilling.
. . . less
|
|
|
CM-4000 Series
|
1 5/8" Mushroom Pushbutton with Aluminum Faceplate (Single Gang)
. . . more
1 5/8" Mushroom Pushbutton with Aluminum Faceplate (Single Gang)
. . .
CM-4000 Series mushroom switches are vailable in multiple colors, with various engraved logos or words. and feature Heavy duty cast aluminum faceplates, in single gang or narrow widths.
. . . less
|
|
|
Series 30
|
BHMA Grade 3
. . . more
BHMA Grade 3
. . .
Designed for medium duty applications, Series 30 strikes are Fail Secure and available in a range of voltages. EZ Fit models can be installed in any standard ANSI strike plate door frame opening.
. . . less
|
|
|
|
Light/Medium Duty Keypads (CM-120i, CM-500SK)
. . . more
Light/Medium Duty Keypads (CM-120i, CM-500SK)
. . .
These light/medium duty models are primarily designed for interior traffic control applications, or for controlling access to equipment or machinery. CM-120i selectable stand alone or Wiegand output keypads control up to 999 users. CM-500SK has a modern, attractive design, and can control up to 500 users.
. . . less
|
|
|
CM-40/41Series
|
All-Active - 4 1/2 Inch Round
. . . more
All-Active - 4 1/2 Inch Round
. . .
All-Active Switches require minimal actuation force and meet ADA standards. Constructed from stainless steel or solid brass, with a choice of faceplate designs and finishes. All models feature Camden's exclusive buffed finish, durable 4 stud switch mount design, rubber dampers for smoother actuation and quiet operation.
. . . less
|
|
|
|
| Product Line: |
|
| Product Type: |
Light Duty
|
|
| Product Category: |
Electric Strikes
|
|
|
|
Login For Pricing
|
