Touchless Switch

CM-324:Hands Free Switch - Hands Free Switches


Touchless Switch - Optional Stainless Steel Faceplate

CM-324:Hands Free Switch - Hands Free Switches


Building Op Management Award

CM-324:Hands Free Switch - Hands Free Switches


CM-324
Hands Free Switch

Sure-Wave™ is recommended for use in barrier-free applications, restrooms, hospitals and clean rooms. Sure-Wave™ is also ideal for commercial and industrial applications where hands-free activation is desired, such as drive-up windows, and kitchen doors in restaurants.

Features
Narrow, single gang and double gang faceplates
Polycarbonate and stainless steel faceplates
Adjustable operating range 3"-26"
Adjustable time delay 1–5 seconds
Fail-safe/non-fail-safe selectable
On-board LED for ease of set-up (selectable on/off)
Excellent performance in all lighting conditions
Fully shielded against EMI, line voltage spikes and noise
Heavy duty 5 amp relay, for use with all automatic operators and electrified locks
Specifications
Operation: Range 3" to 26" (76.2mm to 660mm)
Voltage: 12-24 Volts, AC/DC
Contact Rating: 5 Amps @ 30 VDC
Contact Type: SPDT Form 'C'
Current Draw: 60 mA
Switch Life: 100,000 Operations
Response Time: Super-fast activation response <100ms
Temp Range: -4F to +153F (-20C to +85C)
Switch Type: Momentary

Models
Jamb Width, Polycarbonate Faceplate
CM-324/1N Touchless switch with Plain (blank faceplate)
CM-324/2N Touchless switch with Hand Icon
CM-324/3N Touchless switch with Hand Icon & ?Wave to Open?
CM-324/4N Touchless switch with Hand Icon, 'Wave to Open' & wheelchair symbol
Single Gang, Polycarbonate Faceplate
CM-324/1 Touchless switch with Plain (blank faceplate)
CM-324/2 Touchless switch with Hand Icon
CM-324/3 Touchless switch with Hand Icon & ?Wave to Open?
CM-324/4 Touchless switch with Hand Icon, 'Wave to Open' & wheelchair symbol
Double Gang, Polycarbonate Faceplate
CM-324/1W Touchless switch with Plain (blank faceplate)
CM-324/2W Touchless switch with Hand Icon
CM-324/3W Touchless switch with Hand Icon & ?Wave to Open?
CM-324/4W Touchless switch with Hand Icon, 'Wave to Open' & wheelchair symbol
Single Gang, Stainless Steel Faceplate
CM-324/1S Touchless switch with Plain (blank faceplate)
CM-324/2S Touchless switch with Hand Icon
CM-324/3S Touchless switch with Hand Icon & ?Wave to Open?
CM-324/4S Touchless switch with Hand Icon, 'Wave to Open' & wheelchair symbol
Double Gang, Stainless Steel Faceplate
CM-324/1WS Touchless switch with Plain (blank faceplate)
CM-324/2WS Touchless switch with Hand Icon
CM-324/3WS Touchless switch with Hand Icon & ?Wave to Open?
CM-324/4WS Touchless switch with Hand Icon, 'Wave to Open' & wheelchair symbol
Login For Pricing & Print Materials

Compatible Mounting Boxes
Hide Box Details
Narrow/Jamb
CM-23D CM-23D: CM-324:Hands Free Switch - Hands Free Switches SURFACE BOX, Extra Deep - For wireless. Flame and Impact resistant black polymer (ABS) 1 3/4"W X 4 1/2"H X 1 1/2"D
Single Gang
CM-34BL CM-34BL: CM-324:Hands Free Switch - Hands Free Switches SURFACE BOX, Standard Depth. Double wall, flame/Impact resistant black ABS, 2 3/4"W x 4 1/2"H x 1 3/4"D
CM-34AL CM-34AL: CM-324:Hands Free Switch - Hands Free Switches SURFACE BOX, Standard Depth, threaded conduit entry. Heavy Duty cast aluminum 2 3/4"W X 4 1/2"H X 1 3/4"D
CM-66 CM-66: CM-324:Hands Free Switch - Hands Free Switches FLUSH BOX & DRESS PLATE Standard Depth box with 7" x 7" dress plate. Heavy gauge stainless steel
CM-31 CM-31: CM-324:Hands Free Switch - Hands Free Switches SLEEVE, Cover for standard 2" x 4" surface electrical box. Heavy gauge stainless steel
Double Gang
CM-43CBLA CM-43CBLA: CM-324:Hands Free Switch - Hands Free Switches SURFACE BOX, Standard Depth, provision for wireless. Double wall, flame/Impact resistant black polymer (ABS) 4 1/2"W X 4 1/2"H X 2"D, for CM-324/325 Switches
CM-67 CM-67: CM-324:Hands Free Switch - Hands Free Switches SLEEVE, Cover for standard double gang surface box. Heavy gauge stainless steel
Hide Box Details
Login For Pricing & Print Materials

Resource Center
Sales Literature
SureWave_SaleS_Rev1_Feb11 pdf 0.44MB DOWNLOAD
CM-324_Doorhanger pjpeg 0.62MB DOWNLOAD
CM-324 Spec Sheet pdf 1.38MB DOWNLOAD
Promotion
Product Comparison Chart pdf 0.30MB DOWNLOAD
SureWave SS_Presentation ms-powerpoint 5.89MB DOWNLOAD
Support
CounterTalk_SensorSwitches msword 0.42MB DOWNLOAD
Manuals
CM-324_Inst Instruction_Rev1 pdf 0.81MB DOWNLOAD
