Medium Duty Push/Exit Switch (Extended Button)

CM-8000/8100 Series:Medium Duty Vandal Resistant Push Buttons(Extended Button) - Push / Exit Buttons


CM-8000/8100 Series
Medium Duty Vandal Resistant Push Buttons(Extended Button)
CM-8000 and CM-8100 Series push buttons are vandal resistant; designed and manufactured to meet the stringent demands of exit controls. They are supplied with a 1/4” thick heavy duty brushed aluminum plate in single gang and narrow widths.
*CM-7000R-H model shown
Features
1" diameter, extended, red or green buttons
Mounted on heavy 1/4" thick aluminum plate
Indoor or outdoor applications
Spring return operation
Pneumatic time delay models available
3yr. 'Camden Tough' warranty with '2 for 1' replacement
Specifications
Voltage: 12/24V AC/DC
Contact Type: CM-8000/8100: N/O SPST
CM-8010/8110: N/C SPST
CM-8020/8120: N/O & N/C DPST
CM-8085/8185: N/O & N/C DPST Form 'Z', with Pneumatic Timer
Current Rating: 10A@30V DC
Switch Type: Momentary
Dimensions: CM-8000/8010/8020/8085:
4 1/2" x 2 3/4" x 2 1/4"
(114mm x 70mm x 57mm)
CM-8100/8110/8120/8185:
4 1/2" x 1 /34" x 2 1/4"
(114mm x 44mm x 57mm)
Std. Finish: Brushed Aluminum




Models
Single Gang Faceplate
CM-8000 SPRING RETURN, N/O, MOMENTARY
CM-8010 SPRING RETURN, N/C, MOMENTARY
CM-8020 SPRING RETURN, N/O & N/C, MOMENTARY
CM-8085 SPRING RETURN, DPST 1-60 SEC PNEUMATIC TIME DELAY
Narrow Faceplate
CM-8100 SPRING RETURN, N/O, MOMENTARY
CM-8110 SPRING RETURN, N/C, MOMENTARY
CM-8120 SPRING RETURN, N/O & N/C, MOMENTARY
CM-8185 SPRING RETURN, DPST 1-60 SEC PNEUMATIC TIME DELAY

Options & Finishes
Button Color Options:
CM-xxxxR add 'R' to model # for Red button
CM-xxxxG add 'G' to model # for Green button
Button Engraved Graphic Options
CM-xxxxE Add E to product # for 'EXIT' engraved (in white)
CM-xxxxS Add S to product # for SORTIE engraved (in white)
CM-xxxxSA Add SA to product # for SALIDA engraved (in white)
Faceplate Graphic Options
CM-xxx/2 Add /2 to model # for 'WHEELCHAIR' symbol, blue
CM-xxx/3 Add /3 to model # for 'PUSH TO OPEN', black graphics
CM-xxx/3F Add /3F to model # for 'POUSSEZ POUR OUVRIR', black graphics
CM-xxx/3S Add /3S to model # for 'EMPUJE PARA ABRIR', black
CM-xxx/4 Add /4 to model # for 'WHEELCHAIR' symbol and 'PUSH TO OPEN', black text
CM-xxx/7 Add /7 to model # for 'PUSH TO EXIT'
CM-xxx/7F Add /7F to model # for 'POUSSEZ POUR SORTIR', black
CM-xxx/8 Add /8 to model # for 'PUSH TO LOCK', black
Faceplate Finishes
CM-xxxx-DUR Duranodic (US40) finish


Compatible Mounting Boxes
Hide Box Details
Narrow/Jamb
CM-23D CM-23D: CM-8000/8100 Series:Medium Duty Vandal Resistant Push Buttons(Extended Button) - Push / Exit Buttons SURFACE BOX, Extra Deep - For wireless. Flame and Impact resistant black polymer (ABS) 1 3/4"W X 4 1/2"H X 1 1/2"D
Single Gang
CM-34BL CM-34BL: CM-8000/8100 Series:Medium Duty Vandal Resistant Push Buttons(Extended Button) - Push / Exit Buttons SURFACE BOX, Standard Depth. Double wall, flame/Impact resistant black ABS, 2 3/4"W x 4 1/2"H x 1 3/4"D
CM-34AL CM-34AL: CM-8000/8100 Series:Medium Duty Vandal Resistant Push Buttons(Extended Button) - Push / Exit Buttons SURFACE BOX, Standard Depth, threaded conduit entry. Heavy duty cast aluminum 2 3/4"W X 4 1/2"H X 1 3/4"D
CM-66 CM-66: CM-8000/8100 Series:Medium Duty Vandal Resistant Push Buttons(Extended Button) - Push / Exit Buttons FLUSH BOX & DRESS PLATE Standard Depth box with 7" x 7" dress plate. Heavy gauge stainless steel
CM-31 CM-31: CM-8000/8100 Series:Medium Duty Vandal Resistant Push Buttons(Extended Button) - Push / Exit Buttons SLEEVE, Cover for standard 2" x 4" surface electrical box. Heavy gauge stainless steel
Single Gang (Deep)
CM-34D CM-34D: CM-8000/8100 Series:Medium Duty Vandal Resistant Push Buttons(Extended Button) - Push / Exit Buttons SURFACE BOX, Extra Deep - For wireless. Heavy duty grey polymer 2 3/4" W X 4 1/2"H x 3"D
Hide Box Details

Resource Center
Sales Literature
CM-7000/7100, CM-8000/8100 Series-Spec Sheet pdf 0.44MB DOWNLOAD
CM-4000-5000-7000-8000 Series-Pneumatic Switch-Spec Sheet pdf 0.56MB DOWNLOAD
